浩瀚HH-PLOT Molecular sieve甲烷毛细管柱30m*0.53mm*25um

名称：甲烷毛细管柱

编号：20220719007

规格：30m*0.53mm*25um

型号：HH-PLOT Molecular sieve

使用温度：250°C

应用：HJ-2017环境空气/固定污染源废气中总烃，甲烷，非甲烷总烃的测定 气相色谱法

浩瀚色谱（山东）应用技术开发有限公司建立了毛细管柱-双氢火焰检测器测定非甲烷总烃的方法,经优化色谱条件,获得了*佳的实验条件,并根据氢火焰检测器(FID)的原理探讨氧及非烃类等含碳化合物的响应及影响.研究结果表明,本方法测定总烃的标准曲线为0.9994,当色谱进样量为0.25 m L时,方法精密度为0.12%、方法检出限为0.016 mg·m-3(以碳计)等均符合HJ/T38—1999性能指标的要求.实验结果表明含Cl、O、S类的挥发性化合物在测定非甲烷总烃时,也有不同程度的响应值,对计算总烃浓度产生影响.

Name: Methane capillary column

Number: 20220719007

Specifications: 30m*0.53mm*25um

Model: HH-PLOT Molecular sieve

Operating temperature: 250°C

Application: HJ-2017 Determination of total hydrocarbons, methane, and non-methane total hydrocarbons in ambient air/stationary pollution source waste gas by gas chromatography

Haohan Chromatography (Shandong) Application Technology Development Co., Ltd. established a method for the determination of non-methane total hydrocarbons by capillary column-double hydrogen flame detector. After optimizing the chromatographic conditions, the best experimental conditions were obtained. The principle of this method was used to discuss the response and influence of carbon-containing compounds such as oxygen and non-hydrocarbons. The results showed that the standard curve for the determination of total hydrocarbons by this method was 0.9994, and when the chromatographic injection volume was 0.25 mL, the method precision was 0.12%, The detection limit of the method is 0.016 mg·m-3 (calculated as carbon), etc., which meet the requirements of HJ/T38-1999 performance indicators. The experimental results show that the volatile compounds containing Cl, O, and S are used in the determination of non-methane total hydrocarbons. , there are also different degrees of response values, which have an impact on the calculation of the total hydrocarbon concentration.
