haohan纯氖GB/T 17873-1999中氦/氢测定TDX-01填充柱应用岛津2014上6m*4mm

GB/T 17873-1999 纯氖

本标准被GB/T 17873-2014代替

本标准规定了纯氖产品的要求、试验方法以及包装、标志、贮存和运输等。

本标准适用于空分法制取的氖，它主要用于电光源、红外遥感及科学研究等。

名称：填充柱

固定相：碳分子筛

规格：6m*4mm（内径），0.25-0.40mm

型号：TDX-01

应用：GB/T 17873-1999 纯氖中氦-氢的测定

适用于：

安捷伦490在线/便携，4890,5890,6890,7820,7890,8860,8890

岛津GC-14C，GC-2010，GC-2014，GC-2030

赛默飞1310,1300,1610,1600

瓦里安3800系列

布鲁克PE580,590,680,690

磐诺A90，福立GC9790，华爱，天瑞，天美，GC7900，川仪，北分瑞利，东西电子，鲁南瑞虹，捷岛/科晓

浩瀚色谱（山东）应用技术开发有限公司，研制生产《纯氖中氢-氦测定TDX-01色谱柱应用PE580》，测定纯氖中H2-HE，柱效高，分离良好，效果满意。



Determination of hydrogen and helium content
4.4.1 Method: Use a gas chromatograph equipped with a thermal conductivity detector to determine hydrogen and helium in neon. GB/T 17873-1999
4.4.2 Detection limit: hydrogen; 0.5 x10-6(V/V), Helium: 10 x10-6, (V/V)
4.4.3 Instrument parameters
4.4.3.1 Chromatographic Column: Use a particle size of for chromatographic analysis. Install TDX with a diameter of 0.25-0.40mm into a stainless steel tube with an inner diameter of 4mm and a length of approximately 6m, and activate it with dry bath hydrogen gas at 300 ℃ for 6 hours. Alternatively, use an equivalent chromatographic column.
4.4.3. 2 carrier gases: high-purity hydrogen with a flow rate of 40-60m L/min, purified to a impurity content approximately one quantity lower than that of the tested component
level
44.3.3 Temperature: The detector and column temperature are both at room temperature.
4.4.4 Standard Samples
Neon containing (5-10) x10-6 (V/V) hydrogen, neon containing (50-150) x 10-6, (V/V) helium.
4.4.5 Operation steps:
4.4.5.1 Inject standard sample with gas injection valve, record retention time and peak area or peak height.
4.4.5. Using the same method, enter the sample to be tested and record the retention time, peak area, or peak height.
4.4.5.3 Repeat 4.4 five  1, 4. four five Take the arithmetic mean of two parallel measurement results as the measurement result, with a relative deviation of no more than 10%
