安捷伦GDX-303填充柱安装在赛默飞1310上测定硫化物2m*3mm

GDX-303 是由二乙烯苯和三氯乙烯共聚生成的球形高分子多孔小球。它属于弱极性色谱固定相，其极性基团为 -COOH。

主要特性参数：

特性	参数/描述
化学组成	二乙烯苯、三氯乙烯共聚物
极性	弱极性
*高使用温度	250°C
常见粒度	60-80目, 80-100目, 100-120目
堆密度	数据暂缺
比表面积	数据暂缺 (但其孔径相对较大)

GDX-303 的设计使其对一些特定化合物有很好的分离效果：

硫化物分析：这是 GDX-303 *突出和应用*广泛的领域。它能有效分离和测定多种硫化物，如硫化氢（H₂S）、羰基硫（COS）、二硫化碳（CS₂）和二氧化硫（SO₂） 等。例如，用于煤气、焦炉气中痕量硫化氢（H₂S）和羰基硫（COS）的分析，检出限可达1mg/Nm³。

其他气体分析：除了硫化物，GDX 系列填料（包括 GDX-303）也可用于永久性气体（如 CO、CO₂）和低碳挥发性有机物（C1-C3 烃类）的分离。

浩瀚色谱（山东）应用技术开发有限公司，研制《GDX-303填充色谱柱应用岛津GC2014》：GDX-303 是一款特性独特的色谱填料，尤其擅长分析各种硫化物。如果你在工作中需要检测 H₂S、COS、CS₂、SO₂ 等含硫气体，GDX-303 会是一个值得考虑的选择。使用时，只要注意好老化、载气脱氧等细节，它就能为你提供可靠的分析结果。



名称：不锈钢填充柱

型号：GDX-303

规格：2m*4MM,60-80目

使用温度：240°C

应用：多种硫化物，如硫化氢（H₂S）、羰基硫（COS）、二硫化碳（CS₂）和二氧化硫（SO₂）


GDX-303 is a spherical porous polymer ball formed by copolymerization of divinylbenzene and trichloroethylene. It belongs to weakly polar chromatographic stationary phase, and its polar group is - COOH.
Main characteristic parameters:
Characteristic parameters/description
Chemical composition: copolymer of divinylbenzene and trichloroethylene
Weak polarity
Maximum operating temperature 250 ° C
Common particle sizes: 60-80 mesh, 80-100 mesh, 100-120 mesh
Bulk density data is currently missing
Specific surface area data is currently missing (but its pore size is relatively large)
The design of GDX-303 enables it to have good separation effects on certain specific compounds:
Sulfide analysis: This is the most prominent and widely used field of GDX-303. It can effectively separate and determine various sulfides, such as hydrogen sulfide (H ₂ S), carbonyl sulfide (COS), carbon disulfide (CS ₂), and sulfur dioxide (SO ₂). For example, for the analysis of trace amounts of hydrogen sulfide (H ₂ S) and carbonyl sulfide (COS) in coal gas and coke oven gas, the detection limit can reach 1mg/Nm ³.
Other gas analysis: In addition to sulfides, GDX series fillers (including GDX-303) can also be used for the separation of permanent gases (such as CO, CO ₂) and low-carbon volatile organic compounds (C1 to C3 hydrocarbons).
Haohan Chromatography (Shandong) Application Technology Development Co., Ltd. has developed the "GDX-303 Filled Chromatography Column Application Shimadzu GC2014": GDX-303 is a unique chromatographic packing material, particularly adept at analyzing various sulfides. If you need to detect sulfur-containing gases such as H ₂ S, COS, CS ₂, SO ₂ in your work, GDX-303 would be a worthwhile choice to consider. When in use, as long as you pay attention to details such as aging and carrier gas deoxygenation, it can provide you with reliable analysis results.
Name: Stainless Steel Filled Column
Model: GDX-303
Specification: 2m * 4MM, 60-80 mesh
Operating temperature: 240 ° C
Application: Various sulfides, such as hydrogen sulfide (H ₂ S), carbonyl sulfide (COS), carbon disulfide (CS ₂), and sulfur dioxide (SO ₂)
