岛津有机担体柱402填充柱应用在Shimadzu GC20302m*3mm

402有机担体柱专门为解决一些气相色谱分析中的“难题”而设计，典型应用包括：
有机物中微量水的测定：例如，乙醇、丙酮、酯类、烷烃等溶剂中的水分含量分析。这是其*经典的应用。
低碳数含氧化合物的分析：
醇类：甲醇、乙醇、异丙醇、正丙醇、正丁醇等。
醛酮类：甲醛、乙醛、丙酮、丁酮等。
有机酸：甲酸、乙酸等。
永久性气体和低级烃类的分析：在适当的柱温和检测器（如TCD）下，可以分离O₂, N₂, CH₄, CO, CO₂等。常用于半水煤气、变换气、烟道气的分析。（注：对于H₂的分析效果通常不佳，因其在TCD上出峰极快且与空气峰重叠）。
异味物质分析：例如，包装材料中的残留溶剂、酒类中的风味物质等。
4. 使用注意事项
柱效相对较低：与现代高性能的毛细管柱（如WCOT柱）相比，其理论塔板数较低，分离能力有限。
色谱峰可能较宽：导致灵敏度稍低。
需要活化：新柱或长期未使用的色谱柱在使用前必须进行活化（老化），以去除柱子中吸附的水分和其它挥发性物质。活化方法通常是在高于使用温度20-30°C（但不超过*高使用温度）下，通载气烘烤数小时。
注意样品状态：避免注入含有高沸点或不易挥发物质的样品，这些物质可能会永久吸附在固定相上，污染柱子并导致性能下降。


名称：填充柱

型号：402有机担体

规格：2m*1/8，60-80目

zui高温度：250°C

应用：地下水中硫化氢的测试以及乙酸甲酯和甲酸甲酯的含量测定。

浩瀚色谱（山东）应用技术开发有限公司，研制《 402有机担体色谱柱应用赛默飞1310》：在极性物质，特别是水、醇、醛的分析，以及腐蚀性样品和永久气体的分析方面，它仍然具有不可替代的优势



应用：

安捷伦490在线/便携，4890,5890,6890,7820,7890,8860,8890

岛津GC-14C，GC-2010，GC-2014，GC-2030

赛默飞1310,1300,1610,1600

瓦里安3800系列

布鲁克PE580,590,680,690

磐诺A90，福立GC9790，华爱，天瑞，天美，GC7900，川仪，北分瑞利，东西电子，鲁南瑞虹，捷岛/科晓

The 402 organic support column is specifically designed to solve some "difficult problems" in gas chromatography analysis, and typical applications include:
Determination of trace water in organic matter: for example, analysis of water content in solvents such as ethanol, acetone, esters, alkanes, etc. This is its most classic application.
Analysis of low-carbon oxygen-containing compounds:
Alcohols: methanol, ethanol, isopropanol, n-propanol, n-butanol, etc.
Aldehydes and ketones: formaldehyde, acetaldehyde, acetone, butanone, etc.
Organic acids: formic acid, acetic acid, etc.
Analysis of permanent gases and lower hydrocarbons: With appropriate column temperature and detector (such as TCD), O ₂, N ₂, CH ₄, CO, CO ₂, etc. can be separated. Commonly used for the analysis of semi water gas, shift gas, and flue gas. (Note: The analysis effect of H ₂ is usually poor because it peaks very quickly on TCD and overlaps with the air peak).
Analysis of odorous substances: for example, residual solvents in packaging materials, flavor compounds in alcoholic beverages, etc.
4. Precautions for use
Relatively low column efficiency: Compared with modern high-performance capillary columns such as WCOT columns, its theoretical number of trays is lower and its separation ability is limited.
The chromatographic peak may be broad, resulting in slightly lower sensitivity.
Activation required: New or unused chromatographic columns must be activated (aged) before use to remove adsorbed moisture and other volatile substances from the column. The activation method usually involves baking with a carrier gas for several hours at a temperature 20-30 ° C above the operating temperature (but not exceeding the maximum operating temperature).
Attention to sample condition: Avoid injecting samples containing high boiling points or non-volatile substances, as these substances may permanently adsorb onto the stationary phase, contaminate the column, and cause performance degradation.
Name: Filler Column
Model: 402 Organic Carrier
Specification: 2m * 1/8, 60-80 mesh
Zui high temperature: 250 ° C
Application: Testing of hydrogen sulfide in groundwater and determination of the content of methyl acetate and methyl formate.
Haohan Chromatography (Shandong) Application Technology Development Co., Ltd. has developed the "402 Organic Carrier Chromatography Column Application Thermo Fisher Scientific 1310": It still has irreplaceable advantages in the analysis of polar substances, especially water, alcohols, aldehydes, as well as corrosive samples and permanent gases
Application:
Agilent 490 online/portable, 48905890689088608890
Shimadzu GC-14C, GC-2010, GC-2014, GC-2030
Thermo Fisher Scientific 1310130016101600
Varian 3800 Series
Brooke PE580590680690
Panno A90, Fuli GC9790, Huaai, Tianrui, Tianmei, GC7900， Chuanyi, Beifen Ruili, Dongxi Electronics, Lunan Ruihong, Jiedao/Kexiao
