浩瀚MS五A甲烷柱应用在天瑞测定环境空气中微量的CH4含量1m*1/8

MS-5埃 是一种人工合成的硅铝酸盐多孔晶体，其孔径约为 5埃 (0.5 nm)。不同气体分子由于尺寸和极性不同，在通过色谱柱时速度会产生差异，从而实现分离。甲烷（CH₄）能与其他组分（如氧气、氮气）很好地分离开，从而被准确定量。
主要应用场景：这根柱子主要用于 《环境空气和废气监测》 相关标准方法中，准确测定 甲烷 (CH₄) 的浓度，同时也是计算 非甲烷总烃 (NMHC) 的关键。具体适用于：
环境空气、工作场所空气及固定污染源废气中甲烷的测定。
总烃和非甲烷总烃的监测项目。



名称：MS5埃甲烷柱

规格：1m*1/8，60-80Mesh

zui高使用温度：300°C

应用：环境空气/固定污染源废气中总烃，甲烷，非甲烷总烃的测定 气相色谱法

适用于：

安捷伦490在线/便携，4890,5890,6890,7820,7890,8860,8890

岛津GC-14C，GC-2010，GC-2014，GC-2030

赛默飞1310,1300,1610,1600

瓦里安3800系列

布鲁克PE580,590,680,690

磐诺A90，福立GC9790，华爱，天瑞，天美，GC7900，川仪，北分瑞利，东西电子，鲁南瑞虹，捷岛/科晓

浩瀚色谱（山东）应用技术开发有限公司，研制生产的《MS五A甲烷色谱柱应用天瑞VOCS》柱效高，峰型对称，测定固定污染源废气中甲烷，环境空气中CH4，结果满意。


When measuring methane in ambient air, MS-5A packed column is a commonly used chromatographic column choice, which can effectively separate gases such as hydrogen, oxygen, nitrogen, carbon monoxide, and methane
MS-5 angstroms is an artificially synthesized porous crystalline silicate with a pore size of approximately 5 angstroms (0.5 nm). Due to their different sizes and polarities, different gas molecules will experience differences in velocity when passing through a chromatographic column, thus achieving separation. Methane (CH ₄) can be well separated from other components such as oxygen and nitrogen, allowing for accurate quantification.
Main application scenarios: This column is mainly used in the relevant standard methods of "Environmental Air and Waste Gas Monitoring" to accurately determine the concentration of methane (CH4), and is also the key to calculating non methane total hydrocarbons (NMHC). Specifically applicable to:
Measurement of methane in ambient air, workplace air, and fixed source exhaust gases.
Monitoring projects for total hydrocarbons and non methane total hydrocarbons.
Name: MS5 Angstrom Methane Column
Specification: 1m * 1/8, 60-80Mesh
Maximum operating temperature: 300 ° C
Application: Determination of Total Hydrocarbons, Methane, and Non Methane Total Hydrocarbons in Environmental Air/Fixed Source Waste Gas by Gas Chromatography
Suitable for:
Agilent 490 online/portable, 48905890689088608890
Shimadzu GC-14C, GC-2010, GC-2014, GC-2030
Thermo Fisher Scientific 1310130016101600
Varian 3800 Series
Brooke PE580590680690
Panno A90, Fuli GC9790, Huaai, Tianrui, Tianmei, GC7900， Chuanyi, Beifen Ruili, Dongxi Electronics, Lunan Ruihong, Jiedao/Kexiao
Haohan Chromatography (Shandong) Application Technology Development Co., Ltd. has developed and produced the "MS 5A Methane Chromatography Column Application Tianrui VOCS" with high column efficiency and symmetrical peak shape. It has been used to determine methane in fixed pollution source exhaust gas and CH4 in ambient air with satisfactory results.
